Angle steel

Standard

U.S. Standard
British Standard
Australian Standard
European Standard

Model

A36
A92
A572Gr50
S275JR
S355JR
S355J2
S355NL

Category：

Angle steel

Tel:+86-18365739866

WhatsApp:+86-18365739866

Email:Luna@tonghuisteel.com

（L） Equal Angle

Dimensions and Sectional Properties（1） EN10056-1:1999 EN10056-2:1993 EN10163-3:2004

Designation Bezeichnung	Unit Weight (kg/m)	Dimensions Abmessungen (mm)				Sectional Area mm² x10m²
Designation Bezeichnung	G	H=B	t	r1	r2
L 20 x 20 x 3-	0,879	20	3	3,5	2,0	1,12
L 25 x 25 x 3-/ ▲	1,11	25	3	3,5	2,0	1,42
L 25 x 25 x 4-/	1,45	25	4	3,5	2,0	1,85
L 30 x 30 x 3-/ ▲	1,36	30	3	5	2,5	1,74
L 30 x 30 x 4-/	1,78	30	4	5	2,5	2,27
L 35 x 35 x 4-/	2,09	35	4	5	2,5	2,67
L 40 x 40 x 4-/	2,42	40	4	6	3,0	3,08
L 40 x 40 x 5-/	2,97	40	5	6	3,0	3,79
L 45 x 45 x 4*/	2,74	45	4	7	3,5	3,49
L 45 x 45 x 4,5*/-/	3,06	45	4,5	7	3,5	3,90
L 45 x 45 x 5*/	3,38	45	5	7	3,5	4,30
L 50 x 50 x 4-/	3,06	50	4	7	3,5	3,89
L 50 x 50 x 5-/ ▲	3 77	50	5	7	3 5	4 80
L 50 x 50 x 6-/	4 47	50	6	7	3 5	5 69
L 50 x 50 x 7*/	, 5 15	50	7	7	, 3 5	, 6 56
L 55 x 55 x 5*/	, 4,18	55	5	8	, 4,0	, 5,32
L 55 x 55 x 6*/	4,95	55	6	8	4,0	6,31
L 60 x 60 x 4*	3,70	60	4	8	4,0	4,71
L 60 x 60 x 5-/ ▲	4,57	60	5	8	4,0	5,82
L 60 x 60 x 6-/	5,42	60	6	8	4,0	6,91
L 60 x 60 x 8-/ ▲	7,09	60	8	8	4,0	9,03
L 65 x 65 x 6*/	5,91	65	6	9	4,5	7,53
L 65 x 65 x 7-	6,83	65	7	9	4,5	8,70
L 65 x 65 x 8*/	7,73	65	8	9	4,5	9,85
